Flare joint for refrigerants
Features: ● Constructed of a body and flare nut, press and expand the copper tube with a flaring tool (45 degrees) and connect it closely to the body surface. (For use in air-tight applications such as refrigerant piping)
Specifications: Maximum Working Pressure: 7.0 MPa; Regular Usable Pressure: 4.3 MPa; Operating Temperature Range: -4 to 330 degrees F (-20 to 150 degrees C) *Unfrozen
Note: [Example refrigerant for use on high pressure side]; Maximum operating pressure: 3.45 MPa; Compatible refrigerant: R22, R134a, R404A, R407C, R507A; [2 types of compatible refrigerant examples (when used on high pressure side); Maximum operating pressure: 4.30 MPa; Target refrigerant: R410A.
Size (FL): 3/4
Flare screw standard: UNS1" 1/16-14 threads
